Technical data
| Additional data | |
|---|---|
| Battery voltage* | 18 V |
| Torque (soft/hard/max.) | 31/60/- Nm |
| No-load speed (1st gear / 2nd gear) | 0 – 600 / 0 – 1,900 rpm |
| Max. impact rate | 28,500 bpm |
| Chuck capacity, min./max. | 1.5 / 13 mm |
| Torque settings | 20+1 |
| Screw diameter | |
|---|---|
| Max. screw diameter* | 10 mm |
| Max. drilling diameter in wood | 38 mm |
| Max. drilling diameter in steel | 13 mm |
| Max. drilling diameter in masonry* | 13 mm |
| Drilling diameter | |
|---|---|
| Max. screw diameter* | 10 mm |
| Max. drilling diameter in wood | 38 mm |
| Max. drilling diameter in steel | 13 mm |
| Max. drilling diameter in masonry* | 13 mm |
| Total vibration values (Drilling in metal) | |
|---|---|
| Vibration emission value ah | 2.5 m/s² |
| Uncertainty K | 1.5 m/s² |
| Total vibration values (Impact drilling in masonry) | |
|---|---|
| Vibration emission value ah | 8 m/s² |
| Uncertainty K | 1.5 m/s² |
| Total vibration values (Screwdriving) | |
|---|---|
| Vibration emission value ah | 2.5 m/s² |
| Uncertainty K | 1.5 m/s² |
* Highlighted Data
The A-rated noise level of the power tool is typically as follows: Sound pressure level 87 dB(A); Sound power level 98 dB(A). Uncertainty K= 3 dB.
Advantages
Most Compact, powerful Midrange Impact Drill Driver with advanced Kick Back Control and Precision Clutch for enhanced productivity!
- High durability & quality: Full metal chuck and brushless motor
- Innovative Features: Precision Clutch and Kickback Control
- Best in compactness and ergonomics: Shortest head length and new grip shape
Functions
What’s Included in this Package *
in cardboard box with 1 x belt clip, 1 x bit holder, 4 x colour clip
Order number:
0 601 9E9 100
- Cardboard box
- 1 x belt clip, 1 x bit holder, 4 x colour clip
- 1/2 L-BOXX inlay for tool and charger (1 600 A00 2WA, 1 600 A00 2WC)
* Battery and charger not included
