Technical data
| Additional data | |
|---|---|
| No-load speed* | 30,000 rpm |
| Rated input power* | 600 W |
| Tool holder* | Collets up to 8 mm diameter |
| Power output | 350 W |
| Spindle collar diameter | 43 mm |
| Weight | 1.4 kg |
| Max. collet diameter | 8 mm |
| Max. grinding tool diameter | 50 mm |
| Spanner size of locking nut | 19 mm² |
| Spanner size of grinding spindle | 19 mm² |
| Switch | 2-way |
| Total vibration values (Surface grinding up to diameter of 25) | |
|---|---|
| Vibration emission value ah | 3 m/s² |
| Uncertainty K | 1.5 m/s² |
| Total vibration values (Surface grinding up to diameter of 50) | |
|---|---|
| Vibration emission value ah | 8 m/s² |
| Uncertainty K | 1.5 m/s² |
* Highlighted Data
The A-rated noise level of the power tool is typically as follows: Sound pressure level 89 dB(A); Sound power level 100 dB(A). Uncertainty K= 3 dB.
Advantages
The handy tool for universal grinding work
- Compact, ergonomic shape for versatile grinding work
- Powerful 650 watt motor with soft start for fast work progress
- KickBack Control: detects when the tool is jammed and shuts it down immediately
Functions
What’s Included in this Package
with accessory set, (Voltage 240 V)
Order number:
0 601 220 070
- Collet 6 mm 2 608 570 084
- Single-ended open-jaw spanner 1 607 950 525
- Voltage 240 V
