PRO GRL 300 HVG
Rotation Laser
Order number 0.601.061.703
- Green laser line: up to four times better visibility than a red line
- Easy to set up in both the horizontal and vertical modes due to automatic self-levelling of 8% (± 5°)
- The shock warning function, which can be switched on and off, prevents levelling errors in the event of shocks or vibrations
PRO GRL 300 HVG Professional
0 601 061 703
PRO GRL 300 HVG
Your Selection
Technical data
Additional data
Dust and splash protection
IP54
Working range, value
100 m
Working range with receiver
300 m (diameter)
Accuracy
± 3.0 mm at 30 m
Colour of laser line
Green
Laser diode
532 nm, < 5 mW
Operating temperature
0 – 40 °C
Storage temperature
-20 – 70 °C
Laser class
3R
Working range without receiver
100 m (diameter)
Self-levelling range
± 5° (8%)
Levelling time
15 s
Rotation speed
150/300/600 min-¹
Power supply
2 x 1.5 V LR20 (D)
Weight, approx.
1.8 kg
Compatible laser receivers
LR 1G
Slope function
No
